Data Ports
Parallel Port
23063L-003 Rev. 1 12/6/04 R110Xi/R170Xi User Guide 101
18 +5 V at 750 mA
The maximum current draw may be limited by option
configuration.
19–30 Ground
31 ninit
32 nFault/NDataAvail
33, 34 Not used
35 +5 V through a 1.8 KΩ Resistor
36 NSelectin/1284 active
Table 11 • Parallel Cable Pin Configuration (Continued)
36-Pin Connectors Description
