Zebra R110Xi User Manual

RFID Guidelines
Creating Basic RFID Label Formats
23063L-003 Rev. 1 12/6/04 R110Xi/R170Xi User Guide 71
RFID Label Format 2—Write a 64-bit Tag in Hexadecimal
Resulting Label
Programmed to Transponder
1122334455667788
Front Panel Display
Line
Number
Type This ZPL Code Function of ZPL Code
1
^XA
Indicates start of label format.
2
^RS3
Sets tag type to EPC Class 1 64-bit.
3
^FO50,50
^A0N,65
^FDSimple write example
^FS
Prints “Simple write example” on the label at location
50,50.
4
^RFW,H
^FD1122334455667788
^FS
W,H = write hex
Writes the 8 bytes of data (64 bits) to the tag. The data
written is: 1122334455667788
5
^XZ
Indicates end of label format.
Simple write example
RFID TAG DATA
1122334455667788
