Specifications
Print Specifications by Model
23063L-003 Rev. 1 12/6/04 R110Xi/R170Xi User Guide 145
Print Specifications by Model
Refer to the key and the table that follows for printer specifications.
Model Specifications Key This table contains the key for print specifications for the
tables that follows.
R110Xi
Non-Continuous printing (gap, notch, or hole between labels).
Continuous printing (no gap, notch or hole).
Ladder (rotated) orientation.
Picket fence (nonrotated) orientation.
Print Specifications R110Xi 200 dpi R110Xi 300 dpi
Printhead resolution 203 dots/inch (8 dots/mm) 300 dots/inch
(12 dots/mm)
Dot size (width×length) 0.0049×0.0049 in.
(0.125×0.125 mm)
0.0033×0.0033 in.
(0.084×0.084 mm)
First dot location (measured from
inside media edge)
0.10 ± 0.035 in. (2.5 ± 0.89 mm) 0.023 ± 0.035 in.
(0.6 ± 0.9 mm)
Maximum print width 4.09 in. (104 mm) 4.09 in. (104 mm)
Selectable print speeds (inches
per second)
2.4, 3 through 10 2.4, 3 through 8
Maximum Print length 39 in. (991 mm)
150 in. (3810 mm)
39 in. (991 mm)
100 in. (3810 mm)
Bar code modulus (X) dimension 4.9 mil to 49 mil
4.9 mil to 49 mil
3.9 mil to 39 mil
3.33 mil to 33 mil
Thin film printhead with Element
Energy Equalizer (E
3
)
®
Yes Yes
