Introduction
Exterior View
Exterior View
The following illustrations show the exterior of the printer.
Figure 2 • Printer Exterior—Front View
Figure 3 • Printer Exterior—Rear View
1
Front panel
2
Media door
1
Electronics cover
2
Power switch
3
AC power cord connection
