42 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Front Panel Controls
Overview
Overview
After you have installed media and ribbon and printed a configuration label, you can change
the printer’s settings using the front panel controls. For an overview of the front panel,
including descriptions of the buttons and lights, see Front Panel on page 3. If you need to
restore the printer to its factory default settings, see FEED and PAUSE Self Test on page 139.
Many printer settings may be controlled by your printer’s driver or label preparation software.
Refer to the driver or software documentation for more information.
Enter Setup Mode
To enter Setup Mode, complete these steps:
1. Press SETUP/EXIT to enter Setup Mode.
2. Press either NEXT/SAVE or PREVIOUS to scroll through the parameters.
Exit Setup Mode
To leave Setup Mode, complete these steps:
1. Press SETUP/EXIT.
The LCD displays
SAVE CHANGES.
2. Press the left or right oval to display the save options (Table 6).
3. Press NEXT/SAVE to select the displayed choice.
When the configuration and calibration sequence is done,
PRINTER READY displays.
Table 6 • Save Options When Leaving Setup Mode
LCD Display Description
PERMANENT
Permanently saves the changes. Values are stored in the printer even when
power is turned off.
TEMPORARY
Saves the changes until you change them again or until power is turned off.
CANCEL
Cancels all changes from the time you pressed SETUP/EXIT except the
darkness and tear-off settings (if they were changed).
LOAD DEFAULTS
Sets all parameters other than the network settings back to the factory defaults.
To see the factory default values, see Front Panel LCD on page 44.
Note • Loading factory defaults causes the printer to auto-calibrate.
LOAD LAST SAVE
Loads values from the last permanent save.
DEFAULT NET
Sets the wired and wireless network settings back to factory defaults.
