Zebra R110Xi - General Specifications; Electrical Specifications; Environmental Conditions for Operation and Storage

144 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Specifications
General Specifications
General Specifications
Electrical Specifications
Environmental Conditions for Operation and Storage
Dimensions R110Xi R170Xi
Height 15.5 in (393.7 mm) 15.5 in. (393.7 mm)
Width 10.37 in. (263.5 mm) 13.15 in. (334.4 mm)
Depth 19.5 in. (495.3 mm) 19.5 in. (495.3 mm)
Weight without options 51 lb. (25 kg) 67 lb. (30.5 kg)
Power R110Xi R170Xi
General 90 to 264 VAC; 48 to 62 Hz 90 to 264 VAC; 48 to 62 Hz
Power consumption printing
PAUSE test at slowest speed
180 W 220 W
Printer idle 20 W 20 W
Environment Mode Temperature Relative Humidity
Operation Thermal Transfer 41° to 104°F
(5° to 40° C)
20 to 85% non-condensing
Direct Thermal 32° to 104°F
(0° to 40° C)
Storage Thermal Transfer or
Direct Thermal
–40° to 140°F
(–40° to 60° C)
5 to 85% non-condensing
