146 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Specifications
Print Specifications by Model
R170Xi
Print Specifications 170Xi 200 dpi 170Xi 300 dpi
Printhead resolution 203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Dot size (width×length) 0.0049×0.0049 in.
(0.125×0.125 mm)
0.0033×0.0033 in.
(0.084×0.084 mm)
First dot location (measured from
inside media edge)
0.10 ± 0.035 in.
(2.5 ± 0.89 mm)
0.10 ± 0.035 in.
(2.5 ± 0.89 mm)
Maximum print width 6.6 in. (168 mm) 6.6 in. (168 mm)
Selectable print speeds
(in. per second)
2.4, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 2.4, 3, 4, 5, 6, 7, 8
Maximum print length 39 in. (99 cm)
100 in. (381 cm)
39 in. (99 cm)
100 in. (254 cm)
Bar code modulus (X) dimension 3.9 mil to 39 mil
3.33 mil to 33 mil
3.9 mil to 39 mil
3.33 mil to 33 mil
Thin film printhead with Element
Energy Equalizer (E3)
Yes Yes
