Zebra R110Xi - Resolving Print Quality Problems

118 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Routine Maintenance
Clean Interior
Figure 44 • Cleaning the Printhead
4. Rotate the platen roller and clean thoroughly with solvent and an applicator.
5. Brush or vacuum any accumulated paper lint and dust away from the rollers.
6. Reload the media and the ribbon (if required).
7. Close the printhead.
1
Applicator
2
Platen roller
3
Printhead print elements
4
Printhead lever
1
2
3
4
