56 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Front Panel Controls
Front Panel LCD
HEAD TEST COUNT
Setting the Head Test Count
The printer periodically performs a test of the printhead functionality, called a
printhead test or head test. This parameter establishes how many labels are
printed between these internal tests.
1. Press the left oval to move to the next digit position.
2. Press the right oval to increase the value of the digit.
Default: 0000 (disables the test)
Range: 0000 to 9999
HEAD RESISTOR
Setting the Head Resistor Value
Caution • This parameter should be changed only by qualified service
personnel. Do not set the value higher than that shown on the printhead.
Setting a higher value may damage the printhead.
This value has been preset at the factory to match the resistance value of the
printhead. It does not need to be changed unless the printhead or the main logic
board is replaced.
1. Look on the printhead for the label that shows the resistance value (Ω value).
2. Press the left oval to move to the next digit position.
3. Press the right oval to increase the value of the digit.
Initial Value: Factory-set to match the printhead shipped with your printer.
Default Value: 0500
Range: 0500 to 2500
VERIFIER PORT
Setting the Verifier Port
The auxiliary port is used to determine how the printer reacts to the online verifier.
The three operating conditions for this port are:
• OFF: The verifier port is off.
• VER-RPRNT ERR: Label reprinted if verifier detects an error. If a bar code
is near the upper edge of the label, the label is fed out far enough to be verified
and then backfed to allow the next label to print and be verified.
• VER-THRUPUT: Allows greatest throughput but may not indicate a
verification error immediately upon detection. May print from one to three
labels before an error is recognized and printing stops.
• Press the right or left oval to display other choices.
Default: OFF
Selections: OFF, VER-RPRNT, VER-THRUPUT
For more information on the operation of the optional verifier, see the
documentation provided with that option.
Table 7 • Standard LCD Displays (Page 13 of 16)
Parameter Action/Explanation
To Next Page
