Front Panel Controls
Front Panel LCD
23063L-003 Rev. 1 12/6/04 R110Xi/R170Xi User Guide 59
IDLE DISPLAY
Select Idle Display
This parameter selects the LCD options for the real-time clock.
Note • If the default value is not selected, pressing either oval briefly displays the
firmware version of the printer.
• Press the right or left oval to display other choices.
Default: FW (firmware) VERSION
Selections: FW VERSION, MM/DD/YY (24 HR), MM/DD/YY (12 HR),
DD/MM/YY (24 HR), DD/MM/YY (12 HR)
RTC DATE
Set RTC (Real-time clock) Date
This parameter allows you to set the date following the convention selected in
IDLE DISPLAY.
1. Press the left oval to move to the next digit position.
2. Press the right oval to change the value of the digit.
RTC TIME
Set RTC (Real-time clock) Time
This parameter allows you to set the time following the convention selected in
IDLE DISPLAY.
1. Press the left oval to move to the next digit position.
2. Press the right oval to change the value of the digit.
LANGUAGE
Selecting the Display Language
This parameter allows you to change the language used on the LCD.
• Press the right or left oval to display other choices.
Default: ENGLISH
Selections: ENGLISH, SPANISH, FRENCH, GERMAN, ITALIAN,
NORWEGIAN, PORTUGUESE, SWEDISH, DANISH, SPANISH 2, DUTCH,
FINNISH, JAPANESE
Table 7 • Standard LCD Displays (Page 16 of 16)
Parameter Action/Explanation
