Zebra R110Xi User Manual

64 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Front Panel Controls
Front Panel LCD
RFID TAG DATA
Read and Display RFID Tag Data
When this option is selected, the reader attempts to read a tag over the reader, even
if the printhead is open. If no tag data can be read, the text
NO DATA appears on
the bottom line of the display.
If a tag is present, the data for that tag appears on the bottom line of the display in
hexadecimal format. If there is more data than can fit on the bottom line (such as for
96-bit tags), the bottom line will cycle from the first 8 bytes (most significant) to the
next 4 bytes (least significant) approximately every 2 seconds. Whatever
hexadecimal data that can fit on two screens is displayed and cycled through.
For example, if the tag contains the data
0x112233445566778899001122,
when this option is selected, the bottom line of the display shows:
1122334455667788 for 2 seconds followed by 99001122 for 2 seconds. The
printer cycles through these indefinitely.
The printer rereads the tag every cycle, so if the tag changes, data is displayed for
the current tag over the antenna.
Table 9 • RFID LCD Displays (Continued)
Parameter Action/Explanation

Zebra R110Xi Specifications

General

Print Technology/Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi, 300 dpi, 600 dpi
Maximum Print Width	4.09 inches (104 mm)
Maximum Print Length	39 inches
Media Width	1" (25.4 mm) to 4.5" (114 mm)
Memory	16 MB SDRAM
Connectivity/Communication Interfaces	RS-232, USB, Parallel, Ethernet
Operating System Compatibility	Windows, Linux, Mac
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20% to 85% non-condensing
