Zebra R110Xi User Manual

RFID Guidelines
^HR
23063L-003 Rev. 1 12/6/04 R110Xi/R170Xi User Guide 79
• At the end of calibration, a results table is returned to the host. Each line in the results
table appears as:
Row, Read Result, Write Result
where
Row = the dot row where calibration occurred
Read Result = results of calibration (R = read, “ ” = unable to read)
Write Result = results of calibration (W = write, “ ” = unable to write)
Example • If the following command is sent to the printer:
^XA^HR^XZ
The printer starts the transponder calibration and returns a results table such as the following:
start
position=195
215, ,
214, ,
213, ,
212, ,
211, ,
210, ,W
209,R,
208, ,
207, ,
206, ,W
205,R,
204, ,
203, ,
202, ,W
201,R,W
200,R,W
199,R,W
198,R,W
197,R,W
196,R,W
195,R,W <---****
194,R,W
193,R,W
192,R,W
191,R,W
190,R,W
189,R,
188, ,
187, ,
186, ,
185, ,
.
.
.
end
In this example, the optimal programming position is 195. This is identified at the top of the
table (
position=195) and with an the arrow (<---****) in the table.
