Mounting Cradle
To mount the cradle:
1. Align mounting slots on bottom of cradle with studs on plate.
Figure 67 Install Cradle onto Desk Mount
2. Secure cradle to plate using safety screw.
Figure 68 Install Safety Screw
1Studs (3)
1 Safety Screw
1
1
