Zebra TC8300 - Mount Cradle

Accessories
121
Mount Cradle
To mount the cradle:
1. Align mounting slots on bottom of cradle with studs on plate.
Figure 71 Install Cradle onto Desk Mount
2. Secure cradle to plate using two safety screws.
Figure 72 Install Safety Screws
1Studs (4)
1 Safety Screws (2)
1
1
