Zebra TC8300 User Manual

63
Data Capture
Introduction
NOTE: Not available on all configurations
The device has the following data capture options:
• integrated SE965 Standard Range Laser
• integrated SE4770-Standard Range Imager
• integrated SE4850 Extended Range Imager
• integrated digital camera
• optional RS507 Hands-Free Imager.
NOTE: By default, the good decode beep is set to system volume (Notifications). The good decode beep
can be set to another sound (Ringer, Music and Media or Alarms) and the volume can be independently
controlled. See the DataWedge section in the TC8300 Integrator Guide for more information.
Status LED
The Charging/Scan LED indicates data capture status. The LED lights green when a barcode is
successfully decoded.
Figure 21 Charging/Scan LED
Charging/Scan LED

Zebra TC8300 Specifications

General

Display diagonal	4 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Display number of colors	16.78 million colors
USB 2.0 ports quantity	1
Flash memory	128 GB
Internal memory	8 GB
Internal memory type	-
Compatible memory cards	SDXC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	2
Processor family	A110
Processor frequency	1.7 GHz
Battery capacity	6700 mAh
Operating system version	5.1
Operating system installed	Android
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Product color	Black
Phone function	No
International Protection (IP) code	IP65
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	64 mm
Width	76 mm
Height	233 mm
Weight	- g
