Accessories
134
NOTE: Installer should ensure that all building codes are followed when connecting the power supplies to
an AC power source.
While installing the brackets, power supplies and cables:
• Use tie wraps to secure cables to the bracket and rails.
• Coil cables wherever possible.
• Route power cables along the rails.
• Route inter-cradle cables to the side rails and then from the rails to the bracket.
5-Slot Cradle Wall Installation
Use the Rack/Wall Mount Bracket to mount a cradle on a wall. When installing on a wall, first assemble the
bottom tray, install the bottom tray on the wall and then assemble the top tray.
Use mounting hardware (screws and/or anchors) appropriate for the type of wall mounting the bracket
onto. The Mount Bracket mounting slots dimensions are 5 mm (0.2 in.). Fasteners must be able to hold a
minimum of 20 Kg (44 lbs.)
For proper installation consult a professional installer. Failure to install the bracket properly can possibly
result in damage to the hardware.
Bottom Tray Assembly
See steps 1 through 5 in 5-Slot Cradle Rack Installation on page 124.
Bracket Wall Mounting
1. Drill holes and install anchors according to the template supplied with the bracket.
