Zebra TC8300 - Charging the Device

Accessories
106
Figure 55 5-Slot Ethernet Cradle with Battery Charger Setup (Shown on Optional Desk Mount)
Charging the Device
To charge the device:
1. Insert the device into a slot to begin charging.
Figure 56 Insert Device into Cradle
1 AC Line Cord
2 Power Supply
3 DC Line Cord
4 Primary Port
5 Ethernet Cable
6 Router
3
2
1
6
5
4
