Getting Started
21
Setup
Perform these procedures to start using the device for the first time.
1. Install a microSD card (optional)
2. Install the battery
3. Charge the device
4. Power on the device.
Installing the microSD Card
The microSD card slot provides secondary non-volatile storage. The slot is located under the back bezel of
the unit. Refer to the documentation provided with the card for more information, and follow the
manufacturer's recommendations for use.
WARNING: Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card.
Proper ESD precautions include, but are not limited to, working on an ESD mat and ensuring that the
operator is properly grounded.
NOTE: The Condensation Resistant configuration has six screws securing the back bezel.
When installing a microSD card on Condensation Resistant configurations, replace the Back Bezel with
desiccant pack. See Condensation Resistant Rear Bezel Replacement on page 139. Once the Rear Bezel
is removed, the desiccant pack absorbs ambient moisture and can lessen the life of the desiccant pack.
1. Remove the Torx T8 screws holding the back bezel in place.
Figure 3 Remove Screws
20 Hand Strap Mounting
Point
Use for installing the optional hand strap.
21 Proximity Sensor Triggers hands-free, triggerless scanning.
22 NFC tag Tap-to-Pair using NFC (Near Field Communication) - (optional).
