Getting Started
20
Figure 2 Back View
10 Volume Up Button Increases audio volume (programmable).
11 Interface Connector Provides USB host and client communication, audio and device charging via cables
and accessories.
12 Volume Down
Button
Decreases audio volume (programmable).
13
14
16
17
19
20
21
18
15
15
20
22
Standard DPM
16
15
15
20
20
17
19
18
13 Camera Flash Provides illumination for the camera (optional).
14 Camera Takes photos and videos (optional).
15 Speaker Provides audio output.
16 Scanner/Exit Window Provides data capture using the imager or laser scanner.
17 Trigger Initiates data capture (programmable).
18 Programmable Button
(Secondary Trigger)
Initiates Push-To-Talk communication (programmable).
19 Battery Pack Provides power to the device.
