Accessories
129
7.
Slide top tray onto bottom tray until top tray touches vertical power supply.
Figure 84 Slide top Tray onto Bottom Tray
8. Install 16 M2.5 studs onto top tray as shown below.
Figure 85 Install Studs
1Studs (16)
1
