Using the Printer
50
Figure 39 Cleaning Locations (Linered Printer)
Figure 40 Cleaning Locations (Linerless Printer)
Platen Roller
Tear Bar
Gap Sensor
Tear Bar
Printhead
Elements
Black Bar
Sensor
Platen Roller
Platen Holder
Media Support Disk
Media Support
Printhead
Elements
Printer
Frame
Media
Support
