Zebra ZQ520 Maintenance Manual

P1075391-001 • Introduction • -1-12 •
Maximum
Label Size
Flash and
RAM Memory
Installed
Figure 2b: COnFiguratiOn LabeL exampLe (COntinued)
Resident Human
Readable fonts
installed.
Files Loaded in
Printer Memory (will
include Pre-scaled
or Scalable Fonts).
End of Configuration
Report

Zebra ZQ520 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi
Operating Humidity	10% to 90% non-condensing
Storage Humidity	10% to 90% non-condensing
Max Print Width	4.09 in (104 mm)
Connectivity	Bluetooth
Battery	PowerPrecision+
Durability	IP54-rated
Drop Specification	Multiple 6.6 ft./2 m drops to concrete
Media Sensors	Reflective and transmissive
Core Inner Diameter	0.75 in (19 mm)
Thickness	2.3 mil to 5.5 mil
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Weight	1.73 lbs (0.79 kg) with battery
Supported Media Types	labels
Max Print Speed	5 in./127 mm per second
