Zebra ZQ520 Maintenance Manual

P1075391-001 • ZQ520 Replacement Kits • 41 •
ZQ520 Replacement Kits
1 P1072539-001
KIT, REPAIR, PRINTHEAD ASSY, ZQ520
2 P1063406-002
KIT, REPAIR, MLB, ZQ500 SERIES
3 P1072539-002
KIT, REPAIR, MEDIA GUIDE, ZQ520
4 P1072539-003
KIT, REPAIR, MEDIA COVER LINERED, WIFI, ZQ520
4 P1072539-004
KIT, REPAIR, MEDIA COVER LINERED, BT4.0, ZQ520
4 P1072539-005
KIT, REPAIR, MEDIA COVER LINERLESS, WIFI, ZQ520
4 P1072539-006
KIT, REPAIR, MEDIA COVER LINERLESS, BT4.0, ZQ520
5 P1072539-007
KIT, REPAIR, MOTOR ASSY, ZQ520 2
6 P1063406-009
KIT, REPAIR KEYPAD, ZQ500 SERIES, 2
7 P1063406-010
KIT, REPAIR, DISPLAY MODULE ASSY, ZQ500 SERIES
8 P1063406-011
KIT, REPAIR, BT3/802.11G/N RADIO, ZQ500 SERIES
9 P1063406-012
KIT, REPAIR TOP PCBA, ZQ500 SERIES
8 P1063406-013
KIT, REPAIR BT4.0 RADIO, ZQ500 SERIES
10 P1072539-008
KIT, ACC PLATEN CARTRIDGE, LINERED, ZQ520
10 P1072539-009
KIT, ACC PLATEN CARTRIDGE, LINERLESS, ZQ520
11 P1072539-010
KIT, REPAIR, MEDIA COVER BUTTON LATCH, ZQ520 10
12 P1072539-011
KIT, REPAIR, CABLE FLEX GAP SENSOR, ZQ520 3
13 P1072539-012
KIT, REPAIR, PRINTER FRAME ASSY, ZQ520
14 P1063406-019
KIT, REPAIR, PRINTER, GEARS, ZQ500 SERIES SET OF 5
15 P1072539-013
KIT, REPAIR, CONNECTOR DOOR, I/O, ZQ520, 15
16 P1072539-014
KIT, REPAIR, MAG CARD READER, ZQ520
17 P1063406-022
KIT, REPAIR, CABLE DC INPUT CONNECTOR ASSY, ZQ500 SERIES QTY 3
18 P1063406-050
KIT, REPAIR, CABLE MICRO USB ASSY, ZQ500 SERIES QTY 3
ITEM PART # DESCRIPTION
3-51
•

Zebra ZQ520 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi
Operating Humidity	10% to 90% non-condensing
Storage Humidity	10% to 90% non-condensing
Max Print Width	4.09 in (104 mm)
Connectivity	Bluetooth
Battery	PowerPrecision+
Durability	IP54-rated
Drop Specification	Multiple 6.6 ft./2 m drops to concrete
Media Sensors	Reflective and transmissive
Core Inner Diameter	0.75 in (19 mm)
Thickness	2.3 mil to 5.5 mil
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Weight	1.73 lbs (0.79 kg) with battery
Supported Media Types	labels
Max Print Speed	5 in./127 mm per second
