Permitted Towed Vehicle Weight
Model HORTUS CL65 HORTUS HS65
PTO Type Independent Independent
Control Electrohydraulic Electrohydraulic
Rear rpm 540/750/1000 540/750/1000
Diameter mm 35 mm, 6 splines 35 mm, 6 splines
Volumes of
Liquids
Fuel tank L 72 72
Cooling system L 10 10
Crankcase with filter L 8 8
Transmission and hydraulic system L 42 42
Front axle L 16.4 16.4
Dimensions Total Length with 3-point Hitch mm 3,982 3,982
Overall width mm 1,840 1,840
Overall height (without / with
beacon)
mm 2,575/2,619 2,575/2,619
Wheelbase mm 2,155 2,155
Min. Ground Clearance (mm) mm 420 420
Min. Turning Radius without Brakes mm 3,930 3,930
Weight with ROPS or Cab 2,615 2,615
Tires Front 280/85 R20 280/85 R20
Rear 380/85 R30 380/85 R30
Unbraked trailers / semi-trailers 1,100 kg
With overrun brake 6,000 kg
With pneumatic brakes 17,000 kg
