Tachomete
Hour Meter
Fuel Gauge
Water Temperature
Caution: Accelerating excessively rapaid the engine can damage the engine.
This meter shows the revolutions of the engine and the
PTO shafts as well as the travel speed in top gear.
HODP044
It indicates the total time of use. The last digit indicates
one tenth hours. (decimal place) While the hour meter on
the left most section is in operation, the lamp below it
blinks.
HODP045
Shows the amount of fuel in the tank when the ignition
switch is ''ON''.
HODP046
This indicates the coolant temperature after the key switch
is turned to the ''ON'' position.
When the lamp is comes on during driving, it means that
the engine is overheated.
HODP047
DESCRIPTION OF TRACTOR CONTROLS
