Universal Symbols
Some of the universal symbols have been shown below with an indication of their meaning.
Engine
speed rpm x 100)
Air filter PTO engaged Parking brake
Hours, recorded Battery charge PTO disengaged Work lights
Engine coolant
tepmerature
Under pressure,
open slowly
3-point hitch
arms / lifting
Differential lock
Fuel level Variator
3-point hitch
arms /lowering
See Operator´s
manual
Engine stop
indicator light
Warning
Corrosive
substance
-
Position lights Danger warning
Transmission oil
pressure
-
Horn Neutral Turn signal lights
-
Engine oil
pressure
Fan
Transmission oil
temperature
-
