Working and transport position of the front three-point hitc
Driving with agricultural machines attached to the front three-point hitch
The maximum permissible speed of the tractor with agricultural machines attached to the front
three-point hitch is 15 km.h
-1
. If no implement or weight is attached to the front three-point hitch, we
recommend you to lift the lower lifting draw-bars to the transport position.
Changing the position of the draw-bars of the front three-
point hitch:
1. Release and remove the pin (1) from the opening.
2. Lift the arm from position (A) to position (B).
3. Lock the arm by inserting the pin (2) in the opening (2)
and secure the pin.
Only insert the pin in the openings, never check
whether the opening is free with your fingers!
A Working position of the front
three-point hitch
B Transport position of the front
three-point hitch
PCLPN062
DESCRIPTION OF TRACTOR CONTROLS
