Programming - Front Panel
98 025-9567E
The choices are: 0 = Low (or “mark”) is CTS busy
1 = High (or “space”) is CTS busy
Question 6 - Logging Enable
At the following prompt, the encoder expects a single-digit response (0 or 1) which sets the
operating mode for the Model 25 serial port. The default is “0”.
The choices are: 0 = Logging disabled
1 = Logging enabled
The logging enabled (1) setting should only be used if the serial port is connected to a printer
or other logging device and dedicated to that purpose.
Once the single-digit response for “Question 6” has been entered, the Model 25 will
immediately begin to load all changes made in this section to memory to be used until new
changes are made. During the time that the Model 25 is loading this information to memory,
the display will appear as shown here.
CAUTION
Do not remove power or press the RESET button while the Model 25 is loading the
memory, otherwise incorrect information could be loaded requiring reprogramming.
Once the Model 25 completes the loading procedure it will return to the first question in the
General and Send Button programming section, “Question do_” on page 96. You may
program a Send button, make another pass through the Remote Control Setup programming,
or press
RESET to exit the programming mode back to the idle state.
