Z8
®
CPU
User Manual
UM001604-0108 Instruction Description
185
Increment Word
Syntax
INCW dst
Instruction Format
Operation
dst ← dst–1
The contents of the destination (which must be an even address) operand is decremented
by one. The destination operand can be a Register Pair or a Working Register Pair.
Address modes RR or IR can be used to specify a 4-bit Working Register Pair. In this for-
mat, the destination Working Register Pair operand is specified by adding
1110b (Eh) to
the high nibble of the operand. For example, if Working Register Pair R12 (CH) is the des-
tination operand, then
ECh is used as the destination operand in the Op Code.
Example 1
If Register Pairs 30h and 31h contain the value 0AF2h, the statement:
INCW 30h
Op Code: A0 30
leaves the value 0AF3h in Register Pair 30h and 31h. The Z, V, and S Flags are cleared.
Cycles
OPC
(Hex)
Address Mode
dst
OPC dst
10 A0 RR
10 A1 IR
10 A0 R
Flag Description
C Unaffected
Z Set if the result is zero; cleared otherwise.
S Set if the result of bit 7 is set (negative); cleared otherwise.
V Set if arithmetic overflow occurs; cleared otherwise.
D Unaffected
H Unaffected
Edst
Note:
