ZiLOG Z8 Series

Z8
®
CPU
User Manual
UM001604-0108 Instruction Description
186
Example 2
If Working Register R0 contains 30h, and Register Pairs 30h and 31h contain the value
FAF3h, the statement:
INCW @R0
Op Code: A1 E0
leaves the value FAF4h in Register Pair 30h and 31h. The S Flag is set, and the Z and V
Flags are cleared.
