The next figures show the top and bottom side of the power supply board
Figure 8: top view of the power supply board
Figure 9: bottom view of the power supply board
Opening for the
connecting cables for
the vaco device
Mains coil (choke)
Ethernet section
PCB section for Mainboard user
(User interface)
PCB section for Patient Ultrasonic
PCB section for Patient stimulating
current channel1
PCB section for Mains power
PCB section for patient stimulating
current and US Channel 2
SD-card connection
