MAINTENANCE AND FUNCTION / TOOLHEADS
56
CHOOSE A NEW TOOLHEAD
And put it in place.
3
SECURE THE TOOLHEAD
By screwing the nut with provided hex
key.
4
!
If You are using regular extruder insert the plug to le socket.
If you’re using dual extruder, or 5-axis toolhead, insert plugs in le and right sockets.
Turn the power on aer making sure that plugs are positioned correctly.
In case of plastic extruders, also connect small 4-pin plugs powering light and cooling
fan (marked as A).
