ZOE PPM3 - Masimo CO; Capnography

11-10 Nightingale PPM3 User's Guide April 2019
Working With Menus
11.1.6. Masimo CO
2
/ Capnography
Figure 37. Setup CO
2
Menu With Masimo Capnography
Setting
Description
Lower Limit
ETCO
2
& RRc alarm lower limits
Upper Limit
ETCO
2
, RRc, & FICO
2
alarm upper limits
Auto
Auto-adjust lower limits to 80% of current values and upper
limits to 125% of current values.
Alarms On
Enables (Yes) or disables (No) alarms
Print on Alarm
Print a strip chart summary upon alarm conditions
Size
Changes display amplitude of CO
2
waveform
Apnea Time
Time since last breath before RRc alarm annunciates
O
2
Compensation
Adjust CO
2
value based on this range O
2
% in fresh gas
N
2
O Compensation
Adjust CO
2
value based on this range N
2
O% in fresh gas
Zero Set
Initiate manual zeroing of CO
2
sensor (see Masimo CO
2
