Zoom PodTrak P8 User Manual

Use the faders to adjust the levels of each channel in the mix.
Turn ON AIR on or off. When the ON AIR button is off (unlit), sound will not be output to the podcast stereo
le, SPEAKER OUT jacks or USB port.
Turn noise reduction on or off. When multiple mics are being used to record sound, turning this on suppresses
background noise to a constant level by automatically reducing the levels of the mic inputs not being used by
people.
A recording le is made for podcasting. This combines all channels and the SOUND PAD sounds into a stereo
le.
Output the mixed sound of all channels or the playback of audio les on an SD card to speakers with built-in
amplication, for example.
A mix of all channels is output to the computer, smartphone or tablet connected by USB. When the USB Mix
Minus setting ( page 30) is on, the sound input through channel 6 (the USB audio return) is not included.
A mix of all channels is output to the connected smartphone. The sound from the connected smartphone
itself, however, is not sent back to it.
Monitor the sound of the recording for podcasting through headphones. Channels with ON AIR off will also be
output. The volume can be adjusted separately for each pair of headphones.
HINT
Individual les can also be recorded for INPUT 1–6, PHONE and SOUND PAD channels. ( “Setting
recording le types” on page 79)
14

Zoom PodTrak P8 Specifications

Power

phantom power	+48 V
battery type	4 AA batteries
ac adapter	DC 5 V/1 A

Ports & Interfaces

usb type	USB Type-C
headphones output	3.5mm stereo mini
speaker output	TRS jacks

Recording

recorder format	WAV 44.1kHz, 16-bit, mono/stereo
audio interface	44.1kHz, 16-bit, 2-in/2-out
supported media	4–32 GB cards (SDHC), 64–512 GB cards (SDXC)

Display

display type	full-color touchscreen LCD
display size	4.3 inches
display resolution	480×272

Weight and Dimensions

weight	1.43 kg
width	295 mm
depth	248 mm
height	61 mm
