Chapter 7 Wireless
VMG/XMG Series User’s Guide
167
• If users change the modes of a Multy-Pro supported extender, users need to wait until it finishes
booting before creating a MESH network with a controller, a Zyxel router.
See the steps below on how to set up a MESH network. The setup could take you 30 minutes.
Configurations on a Multy-Pro-Supported Extender(s)
1 Prepare a Multy-Pro-supported extender(s) from Zyxel.
The following table lists the Multy-Pro-supported extenders from Zyxel at the time of writing.
2 If the Multy-Pro-supported extender is in repeater mode, enable the wireless LAN. See your Multy-Pro-
supported extender’s UG for how to enable the wireless LAN.
3 If the Multy-Pro-supported extender is in AP mode, connect it to the Zyxel Device using an Ethernet
cable.
4 Turn on the Multy-Pro-supported extender.
5 Enable Zyxel MESH in the Web Configurator. See your Multy-Pro-supported extender’s UG for how to
enable Zyxel MESH.
Configurations on the Zyxel Device
1 If the Multy-Pro-supported extender is in repeater mode, enable the WiFi. See Section 7.2 on page 149 or
Section 3.5 on page 72 for more information on enabling the WiFi.
2 Enable Zyxel MESH in the Network > Wireless > MESH screen.
3 Press the WPS button for more than five seconds on the Zyxel Device.
Or
Click Add Extender in the Multy Pro App. Install from Google Play or the Apple App store.
The following figure shows the Multy Pro application. Device Z is the Zyxel Device. Device A is a Multy-
Pro-supported extender in AP mode. Devices B and C are Multy-Pro-supported extenders in repeater
Mode.
Table 47 Multy-Pro-Supported Extenders from Zyxel
MODELS
WAP6804
WAP6906
WAP7205
