Displaying and Maintaining the Route Policy
To do… Use the command… Remarks
Display IPv4 prefix list statistics display ip ip-prefix [ ip-prefix-name ]
Display IPv6 prefix list statistics display ip ipv6-prefix [ ipv6-prefix-name ]
Display route policy information display route-policy [ route-policy-name ]
Available in any
view
Clear IPv4 prefix list statistics reset ip ip-prefix [ ip-prefix-name ]
Clear IPv6 prefix list statistics reset ip ipv6-prefix [ ipv6-prefix-name ]
Available in user
view
Route Policy Configuration Example
Applying a Route Policy to IPv4 Route Redistribution
Network Requirements
As shown in the following figure, Switch A and Switch B communicate with each other at the network
layer through RIPv2. Switch A has static routes to networks 20.0.0.0/8, 30.0.0.0/8, and 40.0.0.0/8.
Switch B needs to access these networks through Switch A, while Switch A allows Switch B to access
networks 20.0.0.0/8 and 40.0.0.0/8, but not 30.0.0.0/8.
Figure 6-1 Network diagram for route policy application to route redistribution
Configuration procedure
1) Configure Switch A.
# Configure IP addresses of the interfaces (omitted).
# Configure RIP basic functions.
<SwitchA> system-view
[SwitchA] rip
[SwitchA-rip-1] version 2
[SwitchA-rip-1] undo summary
[SwitchA-rip-1] network 192.168.1.0
[SwitchA-rip-1] quit
# Configure three static routes.
[SwitchA] ip route-static 20.0.0.0 255.0.0.0 172.17.1.2
[SwitchA] ip route-static 30.0.0.0 255.0.0.0 172.17.1.2
[SwitchA] ip route-static 40.0.0.0 255.0.0.0 172.17.1.2
# Configure an ACL.
[SwitchA] acl number 2000
