4IPNET EAP210 - EAP727 Hardware Description

User’s Manual
Enterprise Access Point ENGLISH
Copyright © 4IPNET, INC. All rights reserved.
26
EAP727
1
2
3
4
EAP727’s Front Panel EAP727’s Rear Panel
1
LED Indicators
An LED indicator is available to show the uplink status
2
12V 1.0 A
Attach power adaptor here
3
Uplink (PoE) Port
Offers uplink connection. This port can be used to connect to a controller,
gateway, or directly to the Internet. 802.3af PoE is also supported
4
Restart / Reset
Press once to restart the system; to reset the system to factory default
settings, hold for more than 5 seconds.
