4IPNET EAP210 - EAP767 Hardware Description

User’s Manual
Enterprise Access Point ENGLISH
Copyright © 4IPNET, INC. All rights reserved.
30
EAP767
1
2 3
EAP767’s Front Panel EAP767’s Rear Panel
1
LED Indicators
An LED indicator is available to show the uplink status
2
12V 2.5 A
Attach power adaptor here
3
Uplink (PoE) Port
Offers uplink connection. This port can be used to connect to a controller,
gateway, or directly to the Internet. 802.3at PoE is also supported
