4IPNET EAP210 - OWL630 Hardware Description

User’s Manual
Enterprise Access Point ENGLISH
Copyright © 4IPNET, INC. All rights reserved.
34
OWL630
Top
Back
N-type Connector x 6
For connecting to an antenna (RF Card A x 3, RF Card B x 3)
Connector marked –1 is for the primary antenna when the AP is not in
802.11n or 802.11ac mode. Utilize all connectors for optimized MIMO
performance.
Ground Connector
For connecting the ground wire
