Step 2. Connect the EAP727 to your network device. Connect one end of the Ethernet cable to the Uplink
port of EAP727 and the other end of the cable to a switch, a router, or a hub. EAP727 is then
connected to your existing wired LAN network.
Step 3. There are two ways to supply power to EAP727
a) Connect the DC power adaptor to the EAP727 power jack socket.
b) The EAP727 Uplink port is capable of receiving DC currents. Connect a (IEEE 802.3af-
compliant) PSE device (e.g. a PoE-switch) to the Uplink port of EAP727 with the Ethernet cable.
