Step 2. Connect one end of the Ethernet cable to the Uplink port and the other end of the cable to a switch, a
router, or a hub. The EAP767 is now connected to your existing wired LAN network.
Step 3. There are two ways to supply power to EAP767
a) Connect the DC power adaptor to the power jack socket.
b) The Uplink port is capable of receiving PoE. Connect an IEEE 802.3at-compliant PSE device
(e.g. a PoE-switch) to the Uplink port of EAP767 with the Ethernet cable.
