A&D BM-252 - Page 11

BM series 9
Ionizer
Electrode unit of the
ionizer
Separation plate
If unnecessary, remove it.
J
oint handle
When jointed to the right (left) glass
door handle, the right (left) glass
door can be opened or closed with
the left (right) joint handle.
Bubble spirit level
Leveling foot
Glass door handle
The handle for the glass door.
The handle can be jointed to the joint handle
Neutralization
area
Glass door handle
Display cover
LED of the ionizer
Example of BM
-
20
Weighing
chamber
Display
Keys
Grounding terminal
Anti-theft device
AC adapter jack
USB interface
External key
j
ack
Cap the terminal with the accessor
y
rubber cap when it is not used.
RS-232C serial interface
D-sub 9
p
ins
Outlet example
