Illustration, working range IRB 6790 - 205/2.80
This illustration shows the unrestricted working range of the robot.
308
3259
1281
2039
958
2794
ReachHandling capacityRobot type
2.80 m205 kgIRB 6790
Continues on next page
Product manual - IRB 6790 45
3HAC063331-001 Revision: B
© Copyright 2019 - 2020 ABB. All rights reserved.
2 Installation and commissioning
2.2.2 Working range
Continued
