Lubricated screws (Molycote, Gleitmo or equivalent) with allen head screws
The following table specifies the recommended standard tightening torque for
screws lubricated with Molycote 1000, Gleitmo 603 or equivalent with allen head
screws.
Note
A special torque specified in the repair, maintenance or installation procedure
overrides the standard torque.
Tightening torque (Nm)
Class 12.9, lubricated
i
Tightening torque (Nm)
Class 10.9, lubricated
i
Dimension
3528M8
7055M10
12096M12
280235M16
550460M20
950790M24
i
Lubricated with Molycote 1000, Gleitmo 603 or equivalent
