Mounting information
The dimensions for the assembly holes are the same for the replacement
device and the existing device.
To assemble or disassemble the replacement device, grab the device at the housing and not
directly at the S500 module.
Ordering data
Order No. Scope of delivery
1SAP 800 000 R0010 Analog output module 07AC91-AD
1x 2-pole terminal block (3.81 mm grid space)
1x 3-pole terminal block (5.08 mm grid space)
1x 5-pole terminal block (5.08 mm grid space)
4x 8-pole terminal blocks (3.81 mm grid
space)
Replacement devices: I/O modules > Replacement device 07AC91-AD
