152 Parameters
58.17 Transmit delay Defines a minimum response delay in addition to any fixed
delay imposed by the protocol.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control (Refresh settings).
0 ms
0…65535 ms Minimum response delay. 1 = 1
58.18 EFB control word Shows raw (unmodified) status word sent by the drive to the
Modbus controller. For debugging purposes.
This parameter is read-only.
-
0000h…FFFFh Control word sent by Modbus controller to the drive. 1 = 1
58.19 EFB status word Shows raw (unmodified) status word for debugging purposes.
This parameter is read-only.
-
0000h…FFFFh Status word sent by the drive to the Modbus controller. 1 = 1
58.25 Control profile Defines the communication profile used by the protocol.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control (Refresh settings).
ABB Drives
ABB Drives ABB Drives control profile (with a 16-bit control word) 0
DCU Profile DCU control profile (with a 16 or 32-bit control word) 5
58.26 EFB ref1 type Selects the type and scaling of reference 1 received through
the embedded fieldbus interface.
The scaled reference is displayed by 03.09 EFB reference 1.
Note: Applicable only when 79.40 MPPT reference is
disabled. If parameter MPPT reference is enabled, then the
parameter should be set to it’s default value.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows.
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. Scaling: 1 = 100. 2
Torque Torque reference. The scaling is defined by parameter 46.03
Torque scaling.
3
Speed Speed reference. The scaling is defined by parameter 46.01
Speed scaling.
4
Frequency Frequency reference. The scaling is defined by parameter
46.02 Frequency scaling.
5
58.27 EFB ref2 type Not applicable.
58.28 EFB act1 type Selects the type of actual value 1.
Note: Applicable only when 79.40 MPPT reference is
disabled. If parameter MPPT reference is enabled, then the
parameter should be set to it’s default value.
Speed or
frequency
No. Name/Value Description Def/FbEq16
Operation mode Reference 1 type
Speed control Speed
Frequency control Frequency
ACQ80 FW.book Page 152 Thursday, February 14, 2019 11:33 AM
