240 Fieldbus control through the embedded fieldbus interface (EFB)
Modbus holding register addresses
Modbus holding register addresses for the ABB Drives profile and
DCU Profile
The table below shows the default Modbus holding register addresses for the drive
data with the ABB Drives profile. This profile provides a converted 16-bit access to
the drive data.
Note: Only the 16 least significant bits of the drive’s 32-bit Control and Status Words
can be accessed.
Note: Bits 16 through 32 of the DCU Control/Status word are not in use if 16-bit
control/status word is used with the DCU Profile.
Register address Register data (16-bit words)
400001 Default: Control word (CW 16bit). See sections Control Word for the
ABB Drives profile (page 230) and Control Word for the DCU Profile
(page 231).
The selection can be changed using parameter 58.101 Data I/O 1.
400002 Default: Reference 1 (Ref1 16bit).
The selection can be changed using parameter 58.104 Data I/O 4.
400003 Default: Reference 2 (Ref2 16bit).
The selection can be changed using parameter 58.104 Data I/O 4.
400004 Default: Status Word (SW 16bit). See sections Status Word for the
ABB Drives profile (page 234) and Status Word for the DCU Profile
(page 235).
The selection can be changed using parameter 58.104 Data I/O 4.
400005 Default: Actual value 1 (Act1 16bit).
The selection can be changed using parameter 58.105 Data I/O 5.
400006 Actual value 2 (Act2 16bit).
The selection can be changed using parameter 58.106 Data I/O 6.
400007…400014 Data in/out 7…14.
Selected by parameters 58.107 Data I/O 7 …58.114 Data I/O 14.
400015
…400089 Unused
400090
…400100 Error code access. See section Error code registers (holding registers
400090…400100) (page 247).
400101
…465536 Parameter read/write.
Parameters are mapped to register addresses according to parameter
58.33 Addressing mode.
ACQ80 FW.book Page 240 Thursday, February 14, 2019 11:33 AM
