214 Actual signals and parameters
3404
OUTPUT1 DSP
FORM
0…9 1 5
Defines the decimal point location for the first
display parameter.
1…7 – Defines the decimal point location.
• Enter the number of digits desired to the
right of the decimal point.
• See table for example using pi
(3.14159).
8 = BAR METER – Specifies a bar meter
display.
9 = DIRECT – Decimal point location and
units of measure are identical to the
source signal. See Group 01: Operating
data parameter listing for resolution
(which indicates the decimal point
location) and the units of measure.
3405
OUTPUT1 UNIT
0…127 1 4
Selects the units used with the first display parameter.
Note: Parameter is not effective if parameter 3404 OUTPUT1 DSP FORM = 9
(DIRECT).
3406
OUTPUT1 MIN
Depends on selection 1 -
Sets the minimum value displayed for the first display parameter.
Note: Parameter is not effective if parameter 3404 OUTPUT1 DSP FORM = 9
(DIRECT).
Group 34: Panel display
Code Description Range Resolution Default S
3404 value Display Range
0+
3 -32768…+32767
(Signed)
1+
3.1
2+
3.14
3+
3.142
4 3 0…65535
(Unsigned)
53.1
63.14
7 3.142
Note: Parameters 3402, 3403 and 3405…3407
are not effective.
0 = NOT SEL 12 = mV 24 = GPM 36 = l/s 48 = gal/m 60 = ft wg
1 = A 13 = kW 25 = PSI 37 = l/min 49 = gal/h 61 = lbsi
2 = V 14 = W 26 = CFM 38 = l/h 50 = ft
3
/s 62 = ms
3 = Hz 15 = kWh 27 = ft 39 = m
3
/s 51 = ft
3
/m 63 = Mrev
4 = % 16 = °F 28 = MGD 40 = m
3
/m 52 = ft
3
/h 64 = d
5 = s 17 = hp 29 = inHg 41 = kg/s 53 = lb/s 65 = inWC
6 = h 18 = MWh 30 = FPM 42 = kg/m 54 = lb/m 66 = m/min
7 = rpm 19 = m/s 31 = kb/s 43 = kg/h 55 = lb/h 67 = Nm
8 = kh 20 = m
3
/h 32 = kHz 44 = mbar 56 = FPS 68 = Km
3
/h
9 = °C 21 = dm
3
/s 33 = Ohm 45 = Pa 57 = ft/s 69 = min
10 = lb ft 22 = bar 34 = ppm 46 = GPS 58 = inH
2
O 70 = m
3
11 = mA 23 = kPa 35 = pps 47 = gal/s 59 = in wg 71 = m
6
72...116 = RESERVED (Values can be selected from the panel).
117 = %ref 119 = %dev 121 = % SP 123 = Iout 125 = Fout 127 = Vdc
118 = %act 120 = % LD 122 = %FBK 124 = Vout 126 = Tout
The following units are useful for the bar display:
117 = %ref, 118 = %ac, 119 = %dev, 120 = % LD, 121 =% SP, 122 = %FBK, 123 = Iout, 124 =
Vout, 125 = Fout, 126 = Tout, 127 = Vdc.
