Actual signals and parameters 215
3407
OUTPUT1 MAX
Depends on selection 1 -
Sets the maximum value displayed for the first display parameter.
Note: Parameter is not effective if parameter 3404 OUTPUT1 DSP FORM = 9
(DIRECT).
3408
SIGNAL2 PARAM
100…178 1 104
Selects the second parameter (by number) displayed on the control panel. See
parameter 3401 SIGNAL1 PARAM.
3409
SIGNAL2 MIN
Depends on selection 1 -
Defines the minimum expected value for the second display parameter. See
parameter 3402 SIGNAL1 MIN.
3410
SIGNAL2 MAX
Depends on selection 1 -
Defines the maximum expected value for the second display parameter. See
parameter 3403 SIGNAL1 MAX.
3411
OUTPUT2 DSP
FORM
0…9 1 -
Defines the decimal point location for the second display parameter. See parameter
3404 OUTPUT1 DSP FORM.
3412
OUTPUT2 UNIT
0…127 1 1
Selects the units used with the second display parameter. See parameter 3405
OUTPUT1 UNIT.
3413
OUTPUT2 MIN
Depends on selection 1 -
Sets the minimum value displayed for the second display parameter. See parameter
3406 OUTPUT1 MIN.
3414
OUTPUT2 MAX
Depends on selection 1 -
Sets the maximum value displayed for the second display parameter. See parameter
3407 OUTPUT1 MAX.
3415
SIGNAL3 PARAM
100…178 1 120
Selects the third parameter (by number) displayed on the control panel. See
parameter 3401 SIGNAL1 PARAM.
3416
SIGNAL3 MIN
Depends on selection 1 -
Defines the minimum expected value for the third display parameter. See parameter
3402 SIGNAL1 MIN.
3417
SIGNAL3 MAX
Depends on selection 1 -
Defines the maximum expected value for the third display parameter. See parameter
3403 SIGNAL1 MAX.
3418
OUTPUT 3 DSP
FORM
0…9 1 1
Defines the decimal point location for the third display parameter. See parameter 3404
OUTPUT1 DSP FORM.
Group 34: Panel display
Code Description Range Resolution Default S
