Actual signals and parameters 205
1605 USER PAR
SET CHG
Enables the change of the User parameter set through a
digital input. See parameter 9902 APPLIC MACRO. The
change is only allowed when the drive is stopped. During
the change, the drive will not start.
Note: Always save the User parameter set with parameter
9902 after changing any parameter setting, or reperforming
the motor identification. The last settings saved by the user
are loaded into use whenever the power is switched off and
on again or the parameter 9902 setting is changed. Any
unsaved changes will be lost.
Note: The value of this parameter is not included in the
User parameter sets. A setting once made remains despite
User parameter set change.
Note: Selection of User parameter set 2 can be supervised
through relay outputs RO 1…4 and digital output DO. See
parameters 1401 RELAY OUTPUT 1 … 1403 RELAY
OUTPUT 3, 1410 RELAY OUTPUT 4 and 1805 DO
SIGNAL.
NOT SEL
NOT SEL User parameter set change is not possible through a digital
input. Parameter sets can be changed only from the control
panel.
0
DI1 User parameter set control through digital input DI1. Falling
edge of digital input DI1: User parameter set 1 is loaded into
use. Rising edge of digital input DI1: User parameter set 2 is
loaded into use.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DI1,2 User parameter set selection through digital inputs DI1 and
DI2. 1 = DI active, 0 = DI inactive.
7
DI2,3 See selection DI1,2.8
DI3,4 See selection DI1,2.9
DI4,5 See selection DI1,2.10
DI1(INV) User parameter set control through inverted digital input
DI1. Falling edge of inverted digital input DI1: User
parameter set 2 is loaded into use. Rising edge of inverted
digital input DI1: User parameter set 1 is loaded into use.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
All parameters
No. Name/Value Description Def/FbEq
DI1 DI2 User parameter set
0 0 User parameter set 1
1 0 User parameter set 2
0 1 User parameter set 3
